Spare parts kitsGuided check valves - 412S
412S
for submersible pumps, water distribution, high pressure
with PN40 flanges
Description :
- PRESSURE PFA 40 bar / PS in bar θ 100°
- CASING : GJS ductile iron epoxy coated
- With two cable passage notches (412S)
- SEAL : EPDM
- CLOSING SYSTEM : bronze
- GUIDING SYSTEM : DN 2”1/2 bronze, DN > cast iron with bronze ring
| DN | PFA | PS | Cat | Réf. | UV | ||||
| " | mm | water | L1 | L2 | G1 | G2 | |||
| 5 | 125 | 40 | 16 | 40 | 0.5 | 28 | 1 | 149B2254GS | 1 |
| 6 | 150 | 40 | 13 | 40 | 0.5 | 23 | 1 | 149B2255GS | 1 |
| 8 | 200 | 40 | 10 | 40 | 0.5 | 17 | 1 | 149F017096 | 1 |
| 10 | 250 | 40 | 10 | 40 | 0.5 | 14 | 1 | 149B2277GS | 1 |
| 12 | 300 | 40 | 10 | 40 | 0.5 | 11 | 1 | 149B2278GS | 1 |
